CF Pro Series
Indoor Flexible LED Display
Pixel Pitch : 1.56/1.95/2.38/2.6/2.97/3.91mm
Viewing Angle: H:160°V:140°
Refresh Rate: 3840Hz/7680Hz
Protection Level: lP30
Specification
•Panel Weight：8.5 KG ± 10%
•Panel Dimension(W*H*D)：500mm×500mm×108mm
Cylindrical Shape
•Left and Right 0°～±22.5° each, Maximum curve ±45°
Maintenance
•Module Maintenance: Remove the screws from the rear, and push the module forward
Superior Performance
Stick the high quality standard for excellent display effect, stable performance, and maintain well image quality even during long hour operating.
Dual Flexible Modules
Module size: 500mm×250mm
Fewer seams, a flatter surface.
Smoother connections, and superior display quality.
Smooth Curvature Adjustment
Optimized angle-lock switch & comfort-grip rotation mechanism.
Designed to fit hand movements for quick, precise, and effortless angle adjustments.
Cylindrical Shape
Single cabinet max. curved ±45°.
Cylindrical Shape can be achieved by merely 8 cabinets, Minimum outside diameter is 1.273m.
|
Model No. |
CFPro1.5（Indoor） |
CFPro1.9（Indoor） |
CFPro1.9(Indoor) |
CFPro1.9(Indoor) |
CFPro1.9(Indoor) |
CFPro2.38(Indoor) |
CFPro2.6(Indoor) |
CFPro2.9(Indoor) |
CFPro3.9(Indoor) |
|
Pixel Pitch |
1.56mm |
1.9mm |
1.9mm |
1.9mm |
1.9mm |
2.38mm |
2.6mm |
2.9mm |
3.9mm |
|
LED Type |
SMD1212 |
SMD1212 |
SMD1515+HOB |
SMD1212 |
SMD1212 |
SMD1515 |
SMD1515 |
SMD2020 |
SMD2020 |
|
Packing process |
HOB |
2 in 1 |
HOB |
S-SMT |
4 in 1 |
/ |
/ |
/ |
/ |
|
Pixel Density |
409600 pixel/㎡ |
262144 pixel/㎡ |
262144 pixel/㎡ |
262144 pixel/㎡ |
262144 pixel/㎡ |
173056 pixel/㎡ |
147456 pixel/㎡ |
112896 pixel/㎡ |
65536 pixel/㎡ |
|
Panel Resolution |
320*320 pixel |
256*256 pixel |
256*256 pixel |
256*256 pixel |
256*256 pixel |
208*208 pixel |
192*192 pixel |
168*168 pixel |
128*128 pixel |
|
Scan Rate |
1/32 |
1/32or1/16 |
1/32 |
1/32or1/16or1/8 |
1/32 |
1/15 |
1/24or1/16 |
1/21 |
1/16 |
|
Brightness |
700-1000nits |
800-1200nits |
800-1200nits |
800-1200nits |
800-1200nits |
800-1200nits |
800-1200nits |
800-1200nits |
800-1200nits |
|
Color Temperature |
6500-9500K |
||||||||
|
Panel Dimension |
500mm*500mm*108mm |
||||||||
|
Panel Weight |
8.5kg±10% |
||||||||
|
Panel Material |
Die-Casting Cabinet |
||||||||
|
Max. Power Consumption |
≦540w/㎡ |
||||||||
|
Ave. Power Consumption |
≦270w/㎡ |
||||||||
|
Viewing Angle |
H:160°V:140° |
||||||||
|
Refresh Rate |
3840Hz/7680Hz |
||||||||
|
Gray Scale |
14-16bit |
||||||||
|
Working Voltage |
AC100-240V~50/60Hz or AC200-240V~50/60Hz |
||||||||
|
IP Rating |
IP30 |
||||||||
|
Curve |
-45°/-42.5°/- 40°/ -37.5°/ -35°/ -32.5°/- 30°/- 27.5°/-25°/-22.5⁰/-20⁰/-17.5⁰/-15⁰/-12.5⁰/-10⁰/-7.5⁰/-5⁰/-2.5⁰/ 0⁰/2.5⁰/5.0⁰/7.5⁰/10⁰/12.5⁰/15⁰/17.5⁰/20⁰/22.5⁰/ 25°/27.5° /30°/ 32.5°/ 35°/ 37.5°/ 40°/ 42.5°/ 45° |
||||||||
|
Max. Stacking/Hanging Height |
5m |
||||||||
|
Lifetime |
50000h |
||||||||
|
Operating Temp/Humidity |
-20℃~+45℃；10%~60%RH |
||||||||
|
Storage Temp/Humidity |
-40℃~+60℃；10%~60%RH |
||||||||
